Mô tả
Bảng Lựa Chọn Ổ Cắm Phích Cắm Công Nghiệp Bals
| Current | 32A |
| Number of poles | 4p |
| Arangement of phases | 3P+PE |
| Position of earth contact | 3 h |
| Voltage | 380V~(50Hz) 440V~(60Hz) for reefer containers only |
| Frequency | 50/60Hz |
| Protection degree | IP67 |
| Colour code | red RAL 3000 |
| Colour of appliance | Hinged lid red RAL 3000 |
| Bayonet ring grey RAL 7035 | |
| Enclosure grey RAL 7035 | |
| Connection design | with screw terminal |
| Maximum conductor size | 10,0 qmm |
| Cable entry | other |
| Height | 100mm |
| Width | 93.5mm |
| Depth | 100.4mm |
| Flange size vertical in mm | 75mm |
| Flange size horizontal in mm | 75mm |
| Drill hole dist. vertical mm | 60mm |
| Drill hole dist. horizontal mm | 60mm |
| Material of enclosure | Polyamide |
