Bộ Điều Khiển Nhiệt Độ Temperature Winpark AK6


Hãng sản xuất: Winpark

Mã thiết bị: AK6

Bảo hành: 12 Tháng

Xuất xứ: Trung Quốc

Tình trạng: Còn hàng

Xem thêm các Bộ Điều Khiển Nhiệt Độ khác.

Xem thêm các Bộ Điều Khiển Nhiệt Độ của Winpark.


Giá liên hệ

Với số lượng lớn, xin quý khách vui lòng liên hệ trực tiếp để được giá tốt hơn.

Số lượng

Chia sẻ sản phẩm này

Thông số kĩ thuật

—Size: 48mm × 48mm; 48mm × 96mm; 96mm × 48mm; 72mm × 72mm; 96mm × 96mm

—Rated Voltage: AC100(-15%)~240V(+10%)、50/60 HZ

—Power Consumption: ≤5VA

—Dielectric Strength: power-input: 1500V AC 1min; input-relay output: 1500V AC 1min; power-relay output: 1500V AC 1min

—Insulation Resistance: input-relay output: >20MΩ; input-power: >20MΩ; power-relay output: >20MΩ

—Working environment: Ambient temperature: 0℃~50℃; Relative humidity: 35%~85% (no condensation)

—Input Type: K,E,J,N,W3-25,W5-26,S,B,R,T;PT100、CU50、0-5V、0-10V、4-20mA

—Input Impedance: thermocouple: ≤100Ω

—Measurement Range: -200℃—2300℃

—Resolution: 0.1, 1 (adjustable)

—Accuracy: ±0.5%FS

—Relay Output: relay contact: AC220V/ DC30V,3A;resistive load or designation

—Logic Level Output: ON: DC12V (DC9V~15V); OFF: Below DC 0.5V; Max Current: 30mA; load resistance≥1K

—SCR zero cross signal: 100mA

—DC 4-20mA output: allowable load resistance below 500Ω

—Alarm output (up to 2 point): AC220V/DC30V, 3A; resistive load or designation

—Compliance with EMC standards

Manual Temperature Controller Winpark AK6
