Technical Information
| Specifications according to data sheet | DS 95.01 |
| Nominal size | 100 mm |
| Accuracy class | class 1.0 |
| Window | laminated safety glass |
| Case material | Stainless steel 1.4301 |
| Bezel ring | cam ring (bayonet type), stainless steel |
| Connector location | lower mount |
| Diaphragm seal variant | threaded connection, screwed version |
Standard article |
|
| System fill fluid | KN 2 Silicone oil for general applications |
| Process temperature min. | – 10°C |
| Process temperature max. | + 150°C |
| Ambient temperature pressure meas. min | + 10°C |
| Ambient temperature pressure meas. max | + 40°C |
| Gasket | PTFE max. 260°C |
| Fastening parts | Retainer flange and bolts in stainless steel |
