Cảm Biến Quang Photoelectric Sensor Panasonic EX-44

Hãng sản xuất: Panasonic

Mã thiết bị: EX-44

Bảo hành: 12 Tháng

Xuất xứ: Nhật Bản

Tình trạng: Còn hàng

Xem thêm các Cảm Biến Quang khác.

Xem thêm các Cảm Biến Quang của Panasonic.

Giá liên hệ

Chia sẻ sản phẩm này

Thông số kĩ thuật
Item Specifications
Product Number EX-44
Part Number EX-44
Regulatory compliance EMC Directive, RoHS Directive
Sensing range 10 to 70 mm 0.394 to 2.756 in (Conv. point: 40 mm 1.575 in)
with white non-glossy paper (50 x 50 mm 1.969 x 1.969 in)
Min. sensing object dia. 0.2 mm dia. 0.008 in copper wire (Setting distance: 40 mm 1.575 in)
Hysteresis 15 % or less of operation distance with white non-glossy paper (50 x 50 mm 1.969 x 1.969 in)
Repeatability(perpendicular to sensing axis) 0.2 mm 0.008 in or less (Setting distance: 40 mm 1.575 in)
Supply voltage 12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less
Current consumption 35 mA or less
Output NPN open-collector transistor
– Maximum sink current: 100 mA
– Applied voltage: 30 V DC or less (between output and 0 V)
– Residual voltage (Note) : 2 V or less (at 100 mA sink current), 1 V or less (at 16 mA sink current)
(Note) : Old (For production before May 2021) … 1.5 V or less (at 100 mA sink current), 0.4 V or less (at 16 mA sink current)
Output:Utilization category DC-12 or DC-13
Output:Output operation Light-ON
Output:Short-circuit protection Incorporated
Response time 0.5 ms or less
Operation indicator Red LED (lights up when the output is ON)
Stability indicator Green LED (lights up under stable light received condition or stable dark condition)
Sensitivity adjuster Continuously variable adjuster
Timer function –
Pollution degree 3 (Industrial environment)
Protection IP67 (IEC)
Ambient temperature -25 to +55 degrees -13 to +131 degrees Fahrenheit (No dew condensation or icing allowed), Storage: -30 to +70 degrees -22 to +158 degrees Fahrenheit
Ambient humidity 35 to 85 % RH, Storage: 35 to 85 % RH
Ambient illuminance Incandescent light: 3,000 lx or less at the light-receiving face
Voltage withstandability 1,000 V AC for one min. between all supply terminals connected together and enclosure
Insulation resistance 20 MOhm , or more, with 250 V DC megger between all supply terminals connected together and enclosure
Vibration resistance 10 to 500 Hz frequency, 3 mm 0.118 in double amplitude (20 G max.) in X, Y and Z directions for two hours each
Shock resistance 500 m/s2 acceleration (50 G approx.) in X, Y and Z directions three times each
Emitting element Infrared LED (Peak emission wavelength: 880 nm 0.035 mil, modulated)
Material Enclosure: PBT (Polybutylene terephthalate), Lens: Polycarbonate, Display cover: Polycarbonate
(Note) : Old (For production before May 2021) …Polyalylate
Cable 0.2 mm2 3-core cabtyre cable, 2 m 6.562 ft long
Cable extension Extension up to total 100 m 328.084 ft is possible with 0.3 mm2, or more, cable.
Weight Net weight: 45 g approx
Gross weight: 70 g approx
