Mô tả
FCAL50: 50kg, FCAL75: 75kg, FCAL150: 150kg, FCAL300: 300kg
| Material | AISI 420 stainless steel |
| OIML R60 Accuracy class • Verification intervals | C3 • 3000 |
| Nominal load (E max) | 50 – 75 -150 – 300 kg |
| Minimum verification interval (V min) | E max / 10000 |
| Combined error | ≤±0.017% |
| Protection class | IP68 |
| Rated output | 2.0 mV/V ±0.1% |
| Compensated temperature range | -10 °C / +40 °C |
| Input resistance | 400 Ω ±20 |
| Output resistance | 350 Ω ±3 |
| Insulation resistance | >5000 MΩ |
| Safe overload (% of full scale) | 150% |
