Mô tả
| Display type | TFT Color LCD |
| Display size | 10.4″ |
| Resolution | 640 x 480 pixels (VGA) |
| Effective display area | W211.2 x H158.4 mm [W8.31 x H6.24 in.] |
| Display colors | 65,536 colors (No blink) / 16,384 colors (Blink) |
| Backlight | White LED (Not user replaceable. When replacement is required, contact your local distributor.) |
| Backlight service life | 50,000 hrs. or more (each in continuous operation at 25 °C [77 °F] before backlight brightness decreases to 50%) |
| Brightness control | 16 Levels (Adjusted with touch panel or software) |
| Touch panel type | Resistive Film (analog) |
| Touch panel resolution | 1,024 x 1,024 |
| Touch panel lifetime | 1,000,000 times or more |
| Language fonts | Japanese: 6,962 (JIS Standards 1 & 2) (including 607 non-kanji characters), ANK: 158 (Korean, Traditional Chinese, Simplified Chinese, Thai and Cyrillic can be added from the font setting of the screen editor. ) |
| Character sizes | Standard font: 8 x 8, 8 x 16, 16 x 16 and 32 x 32 pixel fonts, Stroke font: 6 to 127 pixel fonts, Image font: 8 to 72 pixel fonts |
| Font sizes | Standard font: Width can be expanded up to 8 times. Height can be expanded up to 8 times.*1 |
| Rated input voltage | 24 Vdc |
| Application memory | When using GP-Pro EX: – Media: FLASH EPROM – Screen Area: 32MB *Use the screen area when the user font area’s capacity is exceeded – for example, when an image font or a picture font is used. – User Font Area: 8MB – Logic Program Area: 132KB (Equivalent to 15,000 steps) *Up to 60,000 steps can be converted in software. However, this reduces application memory capacity (for screen data) by 1 MB. – Free Space: None Removable System: No |
| Backup memory | When using GP-Pro EX: – Screen Area: SRAM 320KB – Variable Area: SRAM 64KB Battery: Replaceable battery / Primary battery for clock data backup |
